Description
Capacity 625 to 3600 liters.
Load < 2400 kg
Qualities
- Tipping body with cubic front door: small footprint for maximum volume.
- Two triggers as standard :
- automatic by touch: no manual intervention required
- by manual lever
- Hinged door with automatic opening assisted by a gas cylinder.
- End of stroke cushioned by rubber stops.
- Door closure with 2 forged hooks.
- Safety latch prevents accidental release.
- Removable feet as standard.
- Maintenance-free equipment.
Features
- Thick bottom plate
4 mm reinforced by 4 plates on field th.
8 mm. - Continuous, reinforced outer weld at inner corners.
- Bowl edges reinforced by folding.
- Thick gripping sleeves 5 mm.
- Articulation on Ø 23 mm axle.
- Paint finish: choice of 10 shades.
Options
- Wheels, lifting lugs, special sleeves, markings, fixed lid with ferrule, fill level, hot-dip galvanized.
- For other specific requirements, please contact us.
Click here to see a video of our front-door tipper.
