Description
Capacity 480 to 1630 kg.
Load < 1800 kg
Qualities
- Ultra-low tipping bucket for low-height workstations (wine press, cutter, shears, filter press).
- End of stroke cushioned by rubber stops.
- Manual lever release.
- Safety latch prevents accidental release.
- Safety link welded to the frame.
- Maintenance-free equipment.
Features
- Mechanically welded assembly in 3 mm sheet metal.
- Continuous, reinforced outer weld at inner corners.
- Bowl edges reinforced by double folding.
- Thick gripping sleeves 5 mm.
- Articulation on Ø 23 mm axle.
- Automatic release on request (height + 50 mm).
- Protective rings Ø 10 mm welded to front panel.
- Equipped with two fixed wheels and two rear swivel wheels with brakes.
- Paint finish: choice of 10 shades.
Options
- Hydraulic tilting, special sheaths, markings, drawbars, hot-dip galvanizing, stainless steel.
- For other specific requirements, please contact us.
Click here to see a video of our ultra-low tipping body.
* Tippers in stock for the following volumes: 480L | 640L | 650L | 815L | 860L | 1080L | 1085L | 1360 | 1630 L (limited stock, please contact us for any request!)
