Description
Capacity 500 to 1200 liters – Loads up to 2200 kgQualities
- Reinforced low tipping body for heavy waste with reduced front height for easy loading.
Complete tilting of the tank regardless of filling volume. - Two triggers as standard :
- automatic by contact.
- by manual lever.
- End of stroke cushioned by rubber stops.
- Safety latch prevents accidental release.
- Safety link welded to the frame.
- Removable feet as standard.
- Maintenance-free equipment.
Features
- Tank sides in thick sheet metal. 3 mm flared to prevent waste from jamming across it.
- Deep-drawn ribs for tank reinforcement.
- Thick bottom plate
4 mm reinforced by 4 plates on field th.
8 mm. - Continuous external and internal welding (watertight tank).
- Bowl edges reinforced by double folding.
- Thick gripping sleeves 5 mm with reinforced belt entry th.
8 mm belt. - Articulation on Ø 23 mm axle.
- Protective rings Ø 10 mm welded to front panel.
- Paint finish: choice of 10 shades.
Options
- Wheels, settling grid + 1/4-turn valve, lifting lugs, special sleeves, markings, tarpaulin, net, manuscopic grip, circular segments for ground reset, hot-dip galvanizing, stainless steel.
- Special manufacture on request.
Click here to see a video of our low-profile reinforced tipper.
