Description
Capacity 850 to 2400 liters – Load less than 1200 kgQualities
- Tipping bucket for flat waste with flared tank in thick sheet metal.
3 mm, flared to prevent waste from jamming across the body.
- Bottom raised at front to prevent slipping during handling.
- Two triggers as standard :
- automatic by contact.
- by manual lever.
- End of stroke cushioned by rubber stops.
- Safety latch prevents accidental release.
- Safety link welded to frame.
- Removable feet as standard.
- Maintenance-free equipment.
Features
- Mechanically welded tank in thick sheet metal. 3 mm flared to prevent waste from jamming across it.
- Tank bottom reinforced by two field-welded plates.
- Continuous, reinforced outer weld at inner corners.
- Bowl edges reinforced by double folding.
- Thick gripping sleeves 5 mm.
- Articulation on Ø 23 mm axle.
- Paint finish: choice of 10 shades.
Options
- Wheels, special sheaths, markings, netting, tarpaulin, hot-dip galvanizing, stainless steel.
- Special manufacture on request.
Click here to see a video of our tipping trailer for flat waste.
