Description
Capacity 1350 to 4000 liters.
Load < 2400 kg
Qualities
- High-capacity tipping body for bulky, low-density waste.
- Reduced height (front height) for easy loading.
- Complete tilting of the tank regardless of filling volume.
- Two triggers as standard :
- automatic by contact.
- by manual lever.
- End of stroke cushioned by rubber stops.
- Safety latch prevents accidental release.
- Safety link welded to the frame.
- Removable feet as standard.
- Maintenance-free equipment.
Features
- Flared bowl to prevent waste from jamming across the bowl.
- Tank bottom reinforced by two field-welded plates.
- Continuous, reinforced outer weld at inner corners.
- Bowl edges reinforced by double folding.
- Thick gripping sleeves 5 mm.
- Articulation on Ø 23 mm axle.
- Protective rings Ø 10 mm welded to front panel.
- Paint finish: choice of 10 shades.
Options
- Wheels, settling grid + 1/4-turn valve, lifting lugs, special sleeves, markings, tarpaulin, net, hot-dip galvanizing, stainless steel.
- For other specific requirements, please contact us.
