Description
Capacity 1350 to 4000 liters.
Load < 2800 kg
Qualities
- High-capacity reinforced tipper for heavy waste.
- Reduced height (front height) for easy loading.
- Complete tilting of the tank regardless of filling volume.
- Two triggers as standard :
- automatic by contact.
- by manual lever.
- End of stroke cushioned by rubber stops.
- Safety link welded to the frame.
- Two safety latches prevent accidental release.
- Removable feet as standard.
- Maintenance-free equipment
Features
- Flared bowl to prevent waste from jamming across the bowl.
- Deep-drawn ribs for tank reinforcement.
- Thick bottom plate
4 mm reinforced by 4 plates on field th.
8 mm. - Continuous external and internal welding (watertight tank).
- Bowl edges reinforced by double folding.
- Thick gripping sleeves 5 mm with reinforced belt entry th.
8 mm belt. - Articulation on Ø 23 mm axle.
- Protective rings Ø 10 mm welded to front panel.
- Paint finish: choice of 10 shades.
Options
- Wheels, settling grid + 1/4-turn valve, lifting lugs, special sleeves, markings, tarpaulin, net, manuscopic grip, circular segments for ground reset, hot-dip galvanizing, stainless steel.
- For other specific requirements, please contact us.
